As you may have noticed, I haven’t been reviewing a lot of cameras as of late. It’s not for a lack of cameras to review, believe me. Much respect to my fellow bloggers especially the ones who do it so regularly. There is no glory to this!
However, I do have a new hobby; camera repair. Or “attempted” camera repair anyway 🙂
Here’s my most recent repair attempt. Some of you may remember my review on the wonderful Polaroid 180 Land camera. If not, and if you’re interested in that camera, you can check out the review here.
THE SHUTTER JAM
The camera was great. However, it started not being so wonderful a few months ago. First it started with the shutter intermittently not firing. It would just jam up for no reason, but then with enough pressing of the shutter release it would fire. Then one day, it stopped firing altogether.
Bummer. I thought this might be it for the mighty 180, but somewhere in the back of my mind I suspected it was not the leaf shutter in the lens itself, but that it was the release mechanism.
I remember reading about loosening up the cable that fires the shutter. On the 180, as with most Land cameras, the shutter release is attached to the main head board which also houses the lens. That area is protected by a metal part that is attached by three very, very tiny screws (if this stuff is confusing you, just refer to the pictures, they tell a much better story than I can!)
When you press the shutter release button (the red one), it actually fires the shutter through a cable, much like a cable release that you attach to your old school SLRs.
Anyway, I did loosen up the cable, but it did not solve the problem. I then tried the opposite, pushing the cable higher thinking perhaps it needed to be closer to get enough tension to fire the shutter. It still didn’t work.
Finally had to loosen up those three very, very tiny screws to take off the part that hides the actual shutter release. This turned out to the the hardest part of the job. It wasn’t supposed to be hard, but I found those screws to be so tiny, even my smallest “eyeglass kit repair” screwdriver wasn’t getting them raggedy screws out.
The space between the front board and the camera means your screwdriver must also be very tiny. There’s not a lot of room to work on this. I don’t have the biggest hands and yet I was having trouble fitting my hand in there while trying to turn the screws loose.
Eventually, I got them off and I’m able to fire the shutter with my finger. It still got jammed so I put in a dab of WD-40 and it’s better now, but not completely fixed. I tried putting the pieces back together, but I found the shutter would release only intermittently with the cable to I just left it off.
I can use it now as is, but since I have to push up the shutter release by hand, I fear it might induce camera shake. Fortunately, the 180 Land Camera has a self timer function and that is what I use if I’m taking shots lower than 1/60. This plus my limited supply of the soon to be extinct packfilm means this is not a camera I’d use any more for taking shots of the kids, especially since they’re always moving around 🙂
This is still an ongoing project and I figure it might be helpful for anyone having similar issues with their Land Camera.
Just like vintage cars, it’s an awesome thing and a lot of fun to shoot with a Camera Legend like the Polaroid 180. However, just like vintage cars, these classic cameras require maintenance and are not so fun when they start getting funky on you.
Just for the record, I did seek out service from a repair place that services these cameras. Never heard back from them. And perhaps that’s a good thing since they saved me money 🙂
THE FILM JAM
While taking my test shots, the film jammed in the 180 as pack film has been known to do. The film is discontinued, pricy, and every picture counts so I did not want to waste anything.
In the past, I have ruined whole packs by trying to force it out. In my 180 review, I mentioned of opening the film back ever so slightly which usually eases tension and allows you to get the film out, but sometimes even that doesn’t work.
In that case, what you need to do is in total darkness, open the film back slowly, pull out the exposed film which should be the one on the very top (assuming you had already pulled the tab enough) and manually put it through the rollers. Again, this must be done in total darkness.
The very top photo of the the dead flowers was actually a saved print using this method.
THE BURNING QUESTION
With the shutter jam and the film jam, I had a whole bunch of “slow jams” to deal with while shooting that Polaroid.
The burning question is, with regards to Polaroids and film altogether: Why Bother?
My best answer for that is: You gotta love it man!! 🙂
I know there’s a lot of folks way more experienced at repairing Land Cameras than I am and I’d love to hear from you!
